Hullámbilincs profil 5 D6

európai termelésből készült

Hullámbilincs profil 5 D6 wie HS105WKP6
Hullámbilincs profil 5 D6 kompatibilis Item 0.0.448.23
Műszaki adatok
Sorozat: Groove 5
Typ: I
Mae (mm): 3040 x 9 x 11
Anyag: AlMgSi0,5F25 natur eloxiert
A kényelem pillanata I x: 0,05 cm4
A kényelem pillanata I y: 0,04 cm4
Az ellenállás pillanata W x: 0,09 cm³
Az ellenállás pillanata W y: 0,07 cm³
Súly: 0,11 Kg/m
TIN: 102515
CAD Adatok
---------------
raktárról

Felhívjuk
Aluminium profile in natural anodized application from European production The shaft clamp profile D6 is used to accommodate the steel shaft 6. After mounting the shaft terminal profile into a profile groove, the shaft is finally penetrated Can be used with all profiles of the class 5 Tolerances for cuts according to DIN ISO 2768 Part 1 m

Itt gyorsan és egyszerűen kérheti az aktuális lehető legjobb árat. Kap egy ajánlatot, beleértve a szállítási időt és a rendelkezésre állást. Általános szabály, hogy a tétel raktáron van.

Ki 3.16 /m netto


Please choose / Bitte wählen




barware Kérjen izmos relé árat
Rúd a` 3040mm

darabolt (beleértve a darabot is) kérjen egy kis ár
Pc. x mm (Milliméter)

választható szerkesztés

----
A vágás a min. 20mm és a max. 3000mm
A csomagküldési szolgáltatással történő szállítás 2400mm
