Hullámbilincs profil 8 D10

európai termelésből készült

Hullámbilincs profil 8 D10 wie HS108WKP10
Hullámbilincs profil 8 D10 kompatibilis Item 0.0.442.03
Hullámbilincs profil 8 D10
Műszaki adatok
Sorozat: Groove 8
Typ: I
Mae (mm): 6040 x 18,2 x 13
Anyag: AlMgSi0,5F25 natur eloxiert
A kényelem pillanata I x: 0,21 cm4
A kényelem pillanata I y: 0,12 cm4
Az ellenállás pillanata W x: 0,21 cm³
Az ellenállás pillanata W y: 0,19 cm³
Súly: 0,208 Kg/m
TIN: 100457
CAD Adatok
---------------
raktárról

Felhívjuk
Aluminium profile in natural anodized application from European production The shaft clamp profile D10 is used to accommodate the steel shaft 10. After mounting the shaft terminal profile into a profile groove, the shaft is finally penetrated Can be used with all profiles of the class 8 Tolerances for cuts according to DIN ISO 2768 Part 1 m

Itt gyorsan és egyszerűen kérheti az aktuális lehető legjobb árat. Kap egy ajánlatot, beleértve a szállítási időt és a rendelkezésre állást. Általános szabály, hogy a tétel raktáron van.

Ki 5.64 /m netto


Please choose / Bitte wählen




barware Kérjen izmos relé árat
Rúd a` 6040mm

darabolt (beleértve a darabot is) kérjen egy kis ár
Pc. x mm (Milliméter)

választható szerkesztés

----
A vágás a min. 20mm és a max. 6000mm
A csomagküldési szolgáltatással történő szállítás 2400mm



Megfelelő tartozékok

Dinamikus elemek

Hullám 10


Görgő 10
